Cement Flow Tables
Used for determining consistency of mortar, lime and cement specimens. Manual and motorized two models are available.
The hand operated model is fitted with a hand wheel.
The motor operated model is driven by a motor speed reducer through a mechanical coupling at the rate of 1 revolution per second. The number of drops is preset on a counter and the machine stops automatically at the end of the cycle.
EN Model, the table is manufactured from stainless steel and Ø300 mm.
The cone made of brass has dimensions of 100mm base dia. x 70mm top dia. x 60mm high. ASTM Model; the table is manufactured from stainless steel and Ø254 mm.
The cone made of brass has dimensions of 100 mm base dia. x 70 mm top dia. x 50 mm height.
Both models are supplied complete with flow mould and tamper.
Technical Specifications :
| Product Code | Product Name | Operated | Table dia. (mm) | Drop Height (mm) | Dimensions (mm) | Weight (kg) | Power Supply |
|---|---|---|---|---|---|---|---|
| NCM-7118 | Cement Flow Table, EN | Hand | Ø300 | 260x260x27 | 260x260x27 | 13 | - |
| NCM-7119 | Cement Flow Table, ASTM | Hand | Ø254 | 260x260x27 | 260x260x27 | 13 | - |
| NCM-7120 | Motorized Cement Flow Table, EN | Motorized | Ø300 | 470x260x350 | 470x260x350 | 36 | 220 V, 50 Hz, 1 ph |
| NCM-7120/60Hz | Motorized Cement Flow Table, EN | Motorized | Ø300 | 470x260x350 | 470x260x350 | 36 | 220 V, 60 Hz, 1 ph |
| NCM-7121 | Motorized Cement Flow Table, ASTM | Motorized | Ø254 | 470x260x350 | 470x260x350 | 36 | 220 V, 50 Hz, 1 ph |
| NCM-7121/60Hz | Motorized Cement Flow Table, ASTM | Motorized | Ø254 | 470x260x350 | 470x260x350 | 36 | 220 V, 60 Hz, 1 ph |
Spare Parts & Accessories :
| Product Code | Product Name | Dimensions (mm) |
|---|---|---|
| NCM-7122/1 | Cement Flow Mould, EN | 100x70x60 |
| NCM-7122/2 | Tamper, 250 gr, EN | Ø40x200 |
| NCM-7122/3 | Cement Flow Mould, ASTM | 100x70x50 |
| NCM-7122/4 | Tamper, Hardwood, ASTM | 13x25x150 |
