Rapid Chloride Permability Tester
Chloride permeability characteristics of concrete can be reliably determined with the Rapid Chloride Permeability Tester.
Rapid Chloride Permeability Tester has 4 channels which independent of each other, 4 channels 16.000 converter for current, 4 channels temperature input and Large Graphic LCD Screen.
The test speed can be adjusted.
Can be monitored the current, voltage, time, temperature and load values over the Large Graphic LCD Screen for each channel as independent.
60 V constant voltage difference property. Accuracy is +/-0.1 V, +/-1 ma.
1 channel temperature sensor input for each cell pair. Independent test start and stop function.
Sound alarm function when starting the experiment and at the end of the experiment. Test values can be stored to memory and The stored values cam be monitored after test.
Rapid Chloride Permeability Tester has 4 pcs. sturdy, transparent cells, temperature sensor for each cell pair, sample connecting Apparatus, Sealing gaskets, voltage supply inputs and different colors inputs for polarities.
Supplied with 4 pcs. Cells, 4 pcs. Supply cable for V(-), 4 pcs. Supply cable for V(+), 4 pcs. Temperature Sensor Connecting cable and device Supply cable.
Technical Specifications :
| Product Code | Product Name | Power Supply |
|---|---|---|
| NPR-5369 | Rapid Chloride Pemeability Tester | 220 V, 50-60 Hz, 1 ph |
Spare Parts & Accessories :
| Product Code | Product Name |
|---|---|
| NPR-5370/1 | Transparent Cell |
| NPR-5370/2 | Supply cable for V(-) |
| NPR-5370/3 | Supply cable for V(+) |
| NPR-5370/4 | Temperature Sensor Connecting Cable |
| NPR-5370/6 | Supply cable |
