Surface Soil Samplers
Used to take field samples of compacted fill or undisturbed soils and to evaluate density of compaction samples as the ground surface.
Steel made, galvanized against corrosion.
The ASTM/CNR version, two models are available.
Both of Surface Soil Sampler (Core Cutter) Sets (Ø 3” and Ø 4”) consists of a drive head, 5 kg drive hammer and a thin wall sampling tube. 5 kg sliding weight drop hammer makes a free-fall on to the driving head which is placed on top of the sampling tube.
The BS version, two models are available.
100 mm Surface Soil Sampler (Core Cutter) Set consists of a driving dolly, 13,5 kg driving rammer and Ø 100 mm x 130 mm high core cutter.
150 mm Surface Soil Sampler (Core Cutter) Set consists of a driving dolly, 16 kg driving rammer and Ø 150 mm x 180 mm high core cutter.
Technical Specifications :
| Product Code | Product Name | Driving Rammer (kg) |
|---|---|---|
| NSS-8013 | Surface Soil Sampler Set, Ø100 mm, BS | 10 |
| NSS-8014 | Surface Soil Sampler Set, Ø150 mm, BS | 16 |
| NSS-8015 | Surface Soil Sampler Set, Ø3", ASTM/CNR | 5 |
| NSS-8016 | Surface Soil Sampler Set, Ø4", ASTM/CNR | 5 |
Spare Parts & Accessories :
| Product Code | Product Name |
|---|---|
| NSS-8017/1 | Sampling Tube Ø100 mm x 130 mm, BS |
| NSS-8018/1 | Sampling Tube Ø150 mm x 180 mm, BS |
| NSS-8019/1 | Sampling Tube Ø3"x70 mm, ASTM/CNR |
| NSS-8020/1 | Sampling Tube Ø4"x157 mm, ASTM/CNR |
