Abrasion Bohme Testing Machine
Abrasion Bohme Testing Machine
The device measures the volume loss in a sample under abrasion testing and is used in the following tests: – paving stones – concrete slabs – slabs made of natural rocks – natural stone slabs.
The device basically consists of a cast iron horizontal disk with a speed of 30 ± 1 rpm and a diameter of 750 mm, equipped with a 200 mm test path for positioning a sample.
Control panel with digital rev counter that automatically stops after 22 rotations.
Abrasive Sand must be ordered separately.
Teknik Özellikler :
| Product Code | Product Name | Dimensions (cm) | Weight (kg) | Power Supply |
|---|---|---|---|---|
| NAM-3101 | Abrasion Bohme Tester | 150x100x85 | 275 | 220 V, 50-60 Hz, 1ph |
Yedek Parçalar ve Aksesuarlar:
| Product Code | Product Name | Weight (kg) |
|---|---|---|
| NAB-3102 | Abrasive Sand | 50 |
